FJ-801
Specification Accessories
FJ-801

IEC 60947-7-1 Standard
  Poles
1
  Voltage / Impulse Voltage
800 V / 8 kV
  Maximum Current
36 A
  Pollution Degree / Voltage Category
  / Material Group
3 / III / I
  Insulating Material
PA 66
  Inflammability Class (acc. to UL94)
V0
Connection Capacity
  Screw Contact / Solder Contact
2 × 4 / 6 mm2
  American Wire Gauge
16 ~ 12 AWG
  Stripping Length
11~12 mm / 0.45 in
Dimensions
  Length
23.6 mm / 0.929 in
  Width
13 mm/ 0.512 in
  Height
18 mm / 0.709 in
