Voltage / Impulse Voltage
800 V / 8 kV
Maximum Current
20 A
Pollution Degree / Voltage Category / Material Group
3 / III / I
Insulating Material
PA 66
Inflammability Class (acc. to UL94)
V0
Wire Range
0.08 ~ 2.5 mm2
American Wire Gauge
28 ~ 12 AWG
Wiring Type
Front-entry
Stripping Length
8 ~ 9 mm / 0.33 in
Length
75 mm / 2.95 in
Width
5 mm / 0.197 in
Height
28 mm / 1.10 in
P9-2.5/4
End Plate
T2.5
Adjacent Jumper
H2.5
Alternate Jumper
ZB-S
Central Marker
E/117
End Bracket
E/119L
E/119R
KLM-A
Terminal Strip Marker
INSD-1
Insulated Screwdriver
