Specification
Accessories |
|
FJ6-6/D
Voltage / Impulse Voltage |
-- / 8 kV |
Maximum Current |
-- |
Pollution Degree / Voltage Category
/ Material Group |
3 / III / I |
Insulating Material |
PA 66 |
Inflammability Class (acc. to UL94) |
V0 |
Rigid Wire |
0.5 ~ 10 mm2 |
Flexible Wire |
0.5 ~ 6 mm2 |
American Wire Gauge |
20 ~ 8 AWG |
Wiring Type |
Front-entry |
Stripping Length |
12 mm |
Width / Length |
8.2 / 69.5 mm |
Height : NS35-7.5 / NS35-15 |
43.5 / 51 mm |
Plug Gauge (acc. to IEC 60947-1) |
A5 | |
FJ6-6/D
P6/6 |
End Plate |
|
FTP-P6 |
Partition Plate |
|
FJS2-8 |
Adjacent Jumper |
|
ZB8 |
Central Marker |
|
ZBF8 |
External Marker |
Coming soon… |
E/117 |
End Bracket |
|
E/119L |
|
E/119R |
|
KLM-A |
Terminal Strip Marker |
|
INSD-1 |
Insulated Screwdriver |
| |
|
