FJ5N/D
Specification Accessories
FJ5N/D

IEC 60947-7-2 Standard
  Voltage / Impulse Voltage
- / 8 kV
  Rated Current / Maximum Current
-
  Pollution Degree / Voltage Category
  / Material Group
3 / III / I
  Insulating Material
PA 66
  Inflammability Class (acc. to UL94)
V0
Connection Capacity
  Rigid Wire
0.2 ~ 6 mm2
  Flexible Wire
0.2 ~ 4 mm2
  American Wire Gauge
24 ~ 10 AWG
  Stripping Length
8 mm
Dimensions
  Width / Length
6.2 / 42.5 mm
  Height : NS35-7.5 / NS35-15 / NS32
47 / 54.5 / 52 mm
  Clamping Screw:
  Screw Thread / Tightening Torque
M3 / 0.6~0.8 Nm
  Fixing Screw:
  Screw Thread / Tightening Torque
M3 / 0.6~0.8 Nm
  Plug Gauge (acc. to IEC 60947-1)
A4
