FKG4
Specification
Accessories
FKG4
IEC / EN Standard
Voltage / Impulse Voltage
-
Rated Current /
Maximum Current
41 /
41 A
Pollution Degree / Voltage Category
/ Material Group
3 / III / I
Insulating Material
PA66
Inflammability Class (acc. to UL94)
V0
Connection Capacity
Rigid Wire
0.5 ~ 6 mm
2
Flexible Wire
0.5 ~ 4 mm
2
American Wire Gauge
20 ~ 10 AWG
Stripping Length
16 mm
Dimensions
Width
/ Length
7
/ 23.5 mm
Height : (NS15)
26 mm
Screw Thread
M4
Plug Gauge (acc. to IEC 60947-1)
A4
Tightening Torque
1.5 ~ 1.8 Nm
FKG4
Accessories
ZB5
Marking Tag
AB/00
Neutral Busbar
AB/01
Support
AB/02
Double Support
AB/03
Support
[
