FJ240
Specification Accessories
FJ240

IEC 60947-7-1 Standard
Voltage / Impulse Voltage
1000 V / 8 kV
Rated Current / Maximum Current
415 / 415 A
Pollution Degree / Voltage Category
/ Material Group
3 / III / I
Insulating Material
PA 66
Inflammability Class (acc. to UL94)
V0
Connection Capacity
Rigid Wire
70 ~ 240 mm2
Flexible Wire
70 ~ 240 mm2
American Wire Gauge
00 ~ 500 AWG
Stripping Length
40 mm
Dimensions
Width / Length
36 / 100 mm
Height : NS35-7.5 / NS35-15 / NS32
- / 131.5 / 129.5 mm
Screw Thread
M10
Plug Gauge (acc. to IEC 60947-1)
B15
Tightening Torque
25~30 Nm
