FJ-405
Specification
Accessories
IEC 60947-7-1 Standard
Poles
5
Voltage / Impulse Voltage
400 V / 4 kV
Maximum Current
32 A
Pollution Degree / Voltage Category
/ Material Group
2 / III / I
Insulating Material
PA 66
Inflammability Class (acc. to UL94)
V0
Connection Capacity
Wire Range
0.08 ~
4 mm
2
American Wire Gauge
28 ~ 10 AWG
Stripping Length
9~10 mm / 0.37 in
Wiring Type
Spring Clamping
Dimensions
Length
20.5 mm / 0.807 in
Width
26.6 mm
/ 1.047 in
Height
14.5 mm / 0.571 in
[
